Ride-on all-electric scissor lift-Suzhou Maigao Lifting Equipment Co., Ltd.

Safety Features

· Platform guardrails are designed in accordance with international safety standards to effectively protect operators when working at height.

· The user can control vehicle movement and platform lifting/lowering independently, enabling continuous operation at height by a single person.

· An emergency stop switch control system is installed to ensure operator safety.

Product Specifications

Parameter	Unit	MG0709	MG0911	MG1113	MG1315
Platform rated load	kg	500	500	500	300
Max. platform height	mm	7000	9000	11000	13000
Min. platform height	mm	1120	1240	1370	1495
Platform size	mm	2150x1140	2150x1140	2150x1140	2150x1140
Outrigger span	mm	2130x2890	2130x2890	2130x2890	2130x2890
Lift motor	V/kW	48/2.2	48/2.2	48/2.2	48/2.2
Drive motor	V/kW	48/2.5	48/2.5	48/2.5	48/2.5
Voltage	V	48	48	48	48
Travel speed	km/h	4-6	4-6	4-6	4-6
Max. gradeability	%	10-15	10-15	10-15	10-15
Battery	V/Ah	4x12V/70Ah	4x12V/70Ah	4x12V/70Ah	4x12V/70Ah
Charger	V/A	48/10	48/10	48/10	48/10
Overall length	mm	2760	2760	2760	2760
Overall width		mm	1295	1295	1295	1295
Overall height	mm	2120	2240	2370	2495
Overall weight	kg	1580	1830	1980	2200

Parameter

Unit

MG0709

MG0911

MG1113

MG1315

Platform rated load

500

300

Max. platform height

7000

9000
